Clearwater SepticTank Range
)
)
Product Information
The Clearwater Septic Tank Range is a cost effective septic tank solution. The design delivers a robust and impact-resistant tank which is ideal for solving your sewage needs. Available in six sizes to service capacity requirements of up to 9,150 litres, our Clearwater Septic Tank Range is suitable for sites such as single and multiple homes, churches, golf courses, farms and mobile homes.
Product Highlights
- MDPE & GRP tanks - strong and durable
- Third-party tested to EN12566 Part 1
- CE marked
- Robust and simple to install for reduced on-site installation time
- Available in six sizes to serve capacity requirements of up to 9,150 litres
- Light and watertight septic tank
- We recommend installing a Klargester BioDisc where possible as they actively treat the sewage
- Free site visit to help select the model to meet your needs - email klargester-web@kingspan.com
Technical Information
Specification
| Model Reference | Capacity (L) | No. of People | Width/Diameter (mm) | Length (mm) | Standard Inlet Invert (mm) | Standard Outlet Invert (mm) | Overall Height (mm) | Pipe Size |
|---|---|---|---|---|---|---|---|---|
| AST029 | 2900 | 6 | 1220 | 2240 | 600-1050* | 650-1100* | 1960-2410* | Ø110mm |
| AST038 | 3800 | 12 | 1220 | 2690 | 600-1050* | 650-1100* | 2100-2550* | Ø110mm |
| STH048 | 4800 | 18 | Ø1425 | 3775 | 500 | 530 | 1750 | Ø110mm |
| STH057 | 5700 | 24 | Ø1425 | 4275 | 500 | 530 | 1750 | Ø110mm |
| STH071 | 7150 | 34 | Ø1920 | 3230 | 500 | 530 | 2190 | Ø160mm |
| STH091 | 9150 | 47 | Ø1920 | 3965 | 500 | 530 | 2190 | Ø160mm |
*Trimmable Inlet Invert
Applications
- Single/Multiple Homes
- Holiday and Residential Caravan sites
- Golf Course toilets
- Churches
- Mobile homes
- Farms
- Temporary work offices e.g. portable cabins
- Offices/Light Industrial Units
- Temporary Dwellings & Welfare Facilities
Legislation
- Third-party tested to EN12566 Part 1
- CE marked
Downloads
Declaration of Performance (DoP)
